DSR-007-OD
DSR-007-OD
Item | Specification | Remark | ||
Model | Soleaf AnY : DSR-007-OD | |||
MCU | ARM Cortex-M4, 100MHz | STM32F417RGT6 | ||
Memory | RAM : 256KB, Flash : 1MB | Internal | ||
Interface | Serial Comm. | 3 port | 2400 ~ 115200bps | |
RS-485 | ||||
LAN | 1 port | RU45, 10/100BASE-T | ||
Maintenance | 1 port | 9600 bps | ||
RS-485 | ||||
Indicator | Status | Blue 1EA | Device | |
LAN | Blue 1EA | Ethernet : Blink | ||
WLAN | Blue 1EA | Ethernet : On | ||
RS 1 | Blue 1EA | Comm. Connected & media type Connected | ||
RS 2 | Blue 1EA | |||
RS 3 | Blue 1EA | |||
Power | DC 5V / 2.7W | Power supply
from external adapter |
||
Temp. range | Operating : -20 ~ +80℃ | Storage : -30℃ ~ 80℃ | ||
Data cycle | 15 minutes |
